Thermona THERM 45 KD

Code: 1065
2 527,20 € –51 %
Thermona THERM 45 KD
2 527,20 € –51 % 1 214 € / pcs
Predaj skončil

Detailed information

Product detailed description

Condensing gas boiler Thermona THERM 45 KD with storage tank connection

Boiler with storage tank connection

The boiler THERM 45 KD extends the successful series of condensing boilers, which have gained an excellent position on the market thanks to their high quality at a reasonable “Czech” price. The continuously modulating output of 13 - 45 kW with high efficiency of combustion and condensation process brings you maximum gas savings in buildings with higher heat demand. However, by using a new combustion chamber made of high-temperature plastic, the boiler maintains its small size, making it easier to adapt to its environment and aesthetics. The high-temperature plastic construction also better resists aggressive condensate and thus positively pushes the boiler's lifetime limit. A three-way valve can be fitted under the boiler, which makes it possible to solve the heating of hot water in an indirectly heated storage tank. Coaxial pipework with a diameter of 80/125 mm is used for venting.

The great advantage of the Therm 45 KD boilers is the possibility of connecting them to cascade boiler rooms. This provides a very economical and environmentally friendly solution for heating and hot water in larger buildings. This intelligent system of condensing cascade boiler rooms is also suitable for older housing construction, e.g. prefabricated houses, where it is one of the most effective revitalisations thanks to its proven qualities.

Jm. heat. performance at Δt = 50/30 °CMin. heat. Performance at Δt = 50/30 °CMin. heating system overpressureMax. heating water outlet temperatureCoax. exhaustJm. supply voltage/frequencyCoverage level el. partsDimensions: height/width/depth
Technical Specificationsjed.45 KD
FuelZP
Appliance CategoriesI2H
Nominal heat inputkW42.5
minimum heat inputkW12.25
kW41.7
kW45
kW13
Gas Consumptionm3.h-11.28-4.52
Max. heating system overpressurebar3
bar0.8
°C80
mm80/125
Average Flue Gas Temperature°C50
Effectiveness%98-106
NOx5
V/Hz230/50
IP 41(D)
Environment according to CSN 33 20 00 - 3base AA5/AB5
boiler weightkg45
mm800/430/370

Additional parameters

Category: Thermona
Warranty: 2 years
