Protherm Gepard Condens 25 MKO + WE 100 ME ľavá + Thermolink P
Code: 0010019893Related products
Product detailed description
Zothava Protherm Chepard Condens 25 MKO
+ Cheetah Condens 25 MKO & nbsp; - suspended condensing boiler with the possibility of connecting a tank
+ WE 100 ME left span > & nbsp; - TV tray, volume: & nbsp; 96 & nbsp; l
+ Thermolink P & nbsp; - eBUS controller
& nbsp;
< strong> PROTHERM GEPARD CONDENS 25 MKO
- suspended condensing boiler with the possibility of connecting an external tank
- power: & nbsp; 6 , 0 - 25,0 kW
- version: < span> & nbsp; turbo & nbsp;
- significant gas savings due to condensing technology and continuous power control,
- heating comfort using outdoor temperature control (equithermal control *),
- hot water preparation in a flow-through manner,
- safety and ease of use thanks to the latest safety features,
- simple control panel with backlit inverted display with excellent readability even in dark rooms and self-diagnostics,
- cooperation with communication controllers - more savings and convenience. < li> low weight and easy installation in the system, whether in new construction or when replacing older boilers
Cheetah Condens 25 MKO & nbsp; | tr>|
Heating | |
Energy class for heating | A |
Power at 80/60 ° C gradient [kW ] | 6.0 - 25.0 |
Power at gradient 50 ° C / 30 ° C [kW] | 6.3 - 26.5 |
Fuel | < td style = "width: 240.641px; text-align: center; "> natural gas|
Efficiency at 80/60 ° C max. power [ %] | 98,2 |
Standard utilization rate at 40/30 ° C [ %] | 108.5 |
Adjustable DHW temperature range [° C] td> | 10 - 80 |
Expansion vessel [l] | < td style = "width: 240.641px; text-align: center; "> 8|
Max working pressure [kPa] | < td style = "width: 240.641px; text-align: center; "> 300|
Flue gas discharge | turbo |
Hot water heating td> | 6.0 - 30.0 & nbsp; (applies to additional tank water heating) td > |
TV supply pressure range [MPa] | - |
Adjustable TV temperature range [° C] | 45 - 60 |
TV flow at 30K [l / min] | - |
Prietok TV pri Δt 35K [l / min] td> | - |
Electrical parameters td > | |
Voltage / Frequency [V / Hz] | 230/50 |
Power [W] | 105 |
Standby power [W] | < td style = "width: 240.641px; text-align: center; "> 2|
Electrical protection [IP] | IPX4D |
Dimensions | |
VS dimensions (width / height / depth) [mm] | 418/740/300 |
Weight without water [kg] td> | 31,6 |
< strong> PROTHERM WE 100/2 ME
- TV hanging tray
- volume: & nbsp; 96 l & nbsp; & nbsp;
- Indirectly heated tank & nbsp; spiral tube heat exchanger
- Net tank volume & nbsp; 96 liters
- Suspended version & nbsp; suitable for kiln boiler assemblies
- Built-in heating & nbsp; 2 kW electric coil & nbsp; as an additional heating method in case of boiler failure
- Corrosion protection & nbsp; magnesium anode
- Minimal heat loss due to new type of insulation & nbsp; rigid PUR foam & nbsp; < / ul>
WEL 100 ME | |
Energy class for hot water production | C |
Domestic water volume td> | 96 l |
Max. operating pressure | 800 kPa |
Heating water connection < / td> | G 3/4" |
< span> Hot water connection | G 1/2 " | tr >
Max. water temperature | 80 ° C |
Maximum possible transmitted power through the tank exchanger | 19.1 kW |
Amount in 10 min. < / span> | 135 l |
First tank warm-up time (from 10 ° C at 60 ° C) | 19 min |
Height / Average < / td> | 955/469 & nbsp; mm |
Weight without water | 41 kg |
Electrical voltage / frequency | 230 V / 50 Hz |
Electrical input span > | 2 kW |
Degree of electrical coverage < / td> | IP21 |
Max. prev. temperature | 70 ° C |
b> PROTHERM THERMOLINK P & nbsp; - room communication controller & nbsp;
eBus & nbsp; > programmable & nbsp; the controller allows you to set one weekly program with the possibility of combining up to 7 different time periods with individually adjustable temperature for heating and hot water heating. from the room temperature and from the set heating program, or in Depending on the outdoor temperature (if an outdoor sensor is connected) with the possibility of automatic optimization of the heating curve. div> Only suitable for the following boiler types: & nbsp; Tiger Condens, Panther Condens, Lev, Panther, Cheetah, Cheetah Condens and Ray electric boiler.
- Reduce heating costs
- Continuous boiler control (eBus )
- Easy control of the controller with text guidance on the backlit display
- Possibility to set the TV temperature with a weekly program
- Option automatic equithermal curve selection
- Optimal heating start to reach the required temperature at the beginning of the time interval
- Recirculation pump control by weekly program li>
- System frost protection
- Display the current time and day of the week and the current room temperature (or outdoor temperature)
Parameters
THERMOLINK P | |
Typ | e-BUS |
Type of program (TV and VV) td > | weekly |
Number of temperature changes per day | 7 |
Room temperature setting range | 5 - 30 ° C |
Regulatory characteristics | smooth |
TV temperature setting range | 38 - 65 ° C |
Setting equithermal curves | < td style = "width: 136.219px; text-align: center; "> yes|
Automatic heating curve | yes |
Holiday traffic | yes |
System frost protection | yes |
Time display | yes |
Recirculation pump control | yes |
Optimal start | yes |
Optical low battery indication | no |
Boiler connection | wired |
& nbsp;
& nbsp;
Additional parameters
Category: | Gepard Condens +100l zásobníkkotol v zostave so 100 l zásobníkom vysoký výkon nad 16 kW Protherm |
---|---|
Warranty: | 2 years |
Weight: | 100 kg |
Určenie kotla: | kotol v zostave so 100 l zásobníkom |
Výkon kotla na vykurovanie: | vysoký výkon nad 16 kW |
Výrobca: | Protherm |
