AVANSA CP 15-1.5 - Circulating water pump for drinking water

Product detailed description

AVANSA CP 15-1.5 - DHW circulation pump for drinking water

Circulation pump intended for the circulation of domestic hot water. Construction improved by technology with
permanent magnets on the rotor, brass body and ceramic shaft enables efficient,
economical and trouble-free operation. The pump is usually installed before the boiler or hot water tank.

Technical parameters:

Max. flow rate (Qmax - l/min): 6.8 l/min
Max. displacement (Hmax - m): 1.7 m
Max. pressure (bar): 10 bar
Motor power (W): 25 W
Power supply (V): 220V/50Hz
Suction DN: 15 mm
DN displacement: 15 mm
Construction length: 85 mm (suction-discharge)
Connection thread: G 1/2"
Temperature range: 5 °C – 95 °C

Advantages:
- massive construction,
- silent operation,
- problem-free operation,
- simple installation,
- pump equipped with a cable with a plug
